Metadata Design: HTTP Headers and Media Types¶

1. Metadata and Representation Headers¶

Metadata in HTTP serves as the "data about data," conveying essential information through headers. Modern REST architecture distinguishes between Request/Response headers (control info) and Representation headers (description of the payload).

2. Content Metadata Rules¶

Rule: `Content-Type` must be used¶

The Content-Type header identifies the media type of the message body. Without it, recipients are forced to perform "MIME-sniffing," which is a significant security risk (e.g., executing a .txt file as a .js script).

Standard: Always include the character encoding if applicable (e.g., application/json; charset=utf-8).

Rule: `Content-Length` should be used¶

This header specifies the size of the body in decimal number of octets (bytes).

Verification: Allows the client to ensure the full payload was received.
Optimization: Allows a HEAD request to determine file size without a full download.
Persistent Connections: Crucial for HTTP/1.1 keep-alive to know where one message ends and the next begins.

Rule: `Last-Modified` should be used in responses¶

A timestamp indicating when the resource was last altered. This enables "Conditional GET" requests via the If-Modified-Since header, saving bandwidth if the resource hasn't changed.

Rule: `ETag` should be used in responses¶

An ETag (Entity Tag) is an opaque, unique identifier (often a hash) for a specific version of a resource.

Validation: Clients store the ETag and send it back in future requests using If-None-Match. If the server's current ETag matches, it returns a 304 Not Modified, instructing the client to use its cached version.

Header	Type	Description
`Last-Modified`	Timestamp	The UTC date and time the resource was last altered.
`ETag`	Opaque String	A unique fingerprint (hash) of the resource's current state.

3. Conditional Requests and Concurrency¶

Rule: Stores must support conditional `PUT` requests¶

Store resources (client-managed) use PUT for both creation and updates. Without conditional headers, a "Lost Update" problem occurs where two clients overwrite each other's changes.

Implementation: APIs must require If-Match or If-Unmodified-Since for PUT operations.
- If-Match: Ensures the client is updating the version they originally retrieved. The operation proceeds only if the current ETag matches the one provided. If not, the server returns 412 Precondition Failed.
- If-Unmodified-Since: Prevents updates if the resource state has shifted since a specific time. The operation proceeds only if the resource hasn't changed since a specific timestamp.
Failure State: If the condition is not met, the server returns 412 Precondition Failed.

4. Redirection and Location¶

Rule: `Location` must specify the URI of new resources¶

The Location header is mandatory for 201 Created responses to point the client to the newly minted URI.

Asynchronous Tasks: In a 202 Accepted response, Location should point to a "Status Monitor" resource where the client can track the progress of the long-running operation.

5. Caching Design¶

Caching is the primary mechanism for improving REST API scalability and reducing latency.

Rule: Use `Cache-Control` to encourage caching¶

The Cache-Control header is the modern standard for defining cacheability.

max-age: Defines freshness in seconds.
must-revalidate: Instructs the cache that once a resource becomes stale, it must be re-validated with the origin server before being served.

Rule: Discourage caching only when necessary¶

Use no-store and no-cache to prevent sensitive or highly volatile data from being stored.

Use no-store to prevent any caching (including the browser's disk cache)
Use no-cache to force revalidation every single time.

Cache-Control: no-store, no-cache, must-revalidate

Modern Pro-Tip: Instead of no-cache, use a very low max-age (e.g., 1 second). This allows for "micro-caching," which can absorb thundering-herd traffic spikes without sacrificing data freshness.

Rule: Support "Negative Caching"¶

Apply Cache-Control headers to 3xx and 4xx responses. Caching a 404 Not Found for a short period (e.g., 60 seconds) prevents repetitive, expensive lookups for resources known to be missing.

6. Custom Headers and Security¶

Rule: Do not use custom headers to change HTTP semantics¶

Custom headers (formerly prefixed with X-, now deprecated per RFC 6648) should only be used for informational purposes (e.g., RateLimit-Limit). They must not be required for basic protocol compliance.

Modern Standard: Security Headers¶

Every REST API in 2026 should implement:

Strict-Transport-Security (HSTS): Enforces HTTPS, forces the browser to use HTTPS only
Content-Security-Policy (CSP): Mitigates XSS, by limits where the browser can load scripts and data from
X-Content-Type-Options: nosniff: Disables MIME-sniffing i.e prevents the browser from trying to guess the Content-Type
X-Frame-Options: Prevents Clickjacking by disallowing the API documentation or UI from being loaded in an <iframe>.

7. Media Types and Negotiation¶

Media Type Syntax¶

The formal syntax for a media type is:

type "/" subtype *( ";" parameter )$$

Common Registered Types¶

Common types include application, audio, image, text, and video.

application/json: The current industry default for structured data.
application/problem+json: The standard for communicating API error details (RFC 7807).
multipart/form-data: Used for file uploads.

Vendor-Specific Media Types (`vnd`)¶

Used to convey domain-specific semantics. While application/json tells you the syntax is JSON, a vendor type tells you the schema.

Vendor-specific types describe the semantics (the "what").

Example: application/vnd.github.v3+json

Rule: Support Content Negotiation¶

Clients use the Accept header to request specific formats.

Accept: application/vnd.example.user+json; q=1.0, application/json; q=0.8

The q parameter (Quality Value) allows the client to rank preferences.

Rule: Support Query Parameter "Tunneling" for Debugging¶

While headers are the standard, allowing ?accept=application/xml facilitates testing via browsers and simple curl commands. This is known as Format Tunneling and should be treated as a secondary override.

When an API is accessed from a browser-based frontend on a different domain, the server must provide CORS headers.

Access-Control-Allow-Origin: Defines which domains are permitted.
Access-Control-Allow-Methods: Defines permitted verbs.
Access-Control-Allow-Headers: Lists which custom headers can be sent.
Access-Control-Expose-Headers: Allows the client to read custom headers like ETag or Location.
